SL4004-US Downlight sv 24V/2,5W, MW2700-5000K, DIA65
SL4004-US Downlight sv 24V/2,5W, MW2700-5000K, DIA65 - Image 2
SL4004-US Downlight sv 24V/2,5W, MW2700-5000K, DIA65 - Image 3
SL4004-US Downlight sv 24V/2,5W, MW2700-5000K, DIA65 - Image 4
SL4004-US Downlight sv 24V/2,5W, MW2700-5000K, DIA65 - Image 5
DOCUMENTS

Technical Drawings

Installation manual

IES

KEY FEATURES

SL4004-US Downlight sv 24V/2,5W, MW2700-5000K, DIA65
Article No. 203.31.22.003
  • CRI 93.
  • High luminous flux
  • Steplessly dimmable.
Contact Us

PRODUCT VARIANTS

PRODUCT INFORMATION – BASIC

Voltage (input)

24 V DC

Wattage

2,5 W

Colour system

multiwhite, 2-pin

Colour temperature

2700 - 5000 K

Colour rendering index CRI Ra

93

Lumen efficacy

122 lm/W

Beam angle

120°

Dimmable

yes

Kind of light

cabinet lights for panel: downlight

Installation

recessed or surface mounting

Area of application

for display, cabinet, shelves

Number of LEDs

40/m

Energy efficiency class

E

Lifetime

L80/B10 > 50.000 h - L70/B50 > 80.000 h

Drill hole

Ø 58 x 13 mm

Material

aluminium + stainless steel

Colour / finish

stainess steel

Modular solution

yes

Scope of delivery

1 light incl. connecting cable 2 m

Order reference / needed accessories

Order base for surface mounting separately.
