LS4031 COB LED-Ribbon 8mm, 24V/8W, MW 2700-5000K

DOCUMENTS

Dialux

Safety instructions

Installation manual

ADDITIONAL INFORMATION ATTRIBUTES

LS4031 COB LED-Ribbon 8mm, 24V/8W, MW 2700-5000K

Article No. 200.11.00.002

COB LED-ribbons offer a wide beam angle of 180° and homogeneous illumination without visible LED dots. LS4031 is intended for use in showrooms and ceiling lighting applications.

CRI 93.
Beam angle 180°.
Steplessly dimmable.
Section length 12,5 mm – the ribbon can be cutted every 12,5 mm.
Installation: self-adhesive.

PRODUCT VARIANTS

LS4031 COB LED-Ribbon 8mm, 24V/8W

LS4031 COB LED-Ribbon 8mm, 24V/8W, MC 2700K

LS4031 COB LED-Ribbon 8mm, 24V/8W, MC 3000K

LS4031 COB LED-Ribbon 8mm, 24V/8W, MC 4000K

LS4031 COB LED-Ribbon 8mm, 24V/8W, MC 5000K

PRODUCT INFORMATION – BASIC

Voltage (output)

24 V DC

Colour system

multiwhite 2-pin

Colour temperature

2700-5000 K

Colour rendering index CRI Ra

93 Luminous flux

680 lm (2700 K), 720 lm (5000 K)

Lumen efficacy

85 lm/W (2700 K), 90 lm/W (5000 K)

Beam angle

180°

Dimmable

yes

Strip width

8 mm

Strip length

5 m

Strip height

1,5 mm

Installation

self-adhesive

Area of application

showroom, ceiling

PRODUCT INFORMATION – DETAIL

Number of LEDs

640/m

Energy efficiency class

F

Lifetime

L80/B10 > 50.000h - L70/B50 > 80.000h

Contact surface length

10 mm

Strip lenght max (visual)

5 m

PRODUCT INFORMATION – SPECIFIC

Material

plastic

Degree of protection

IP20

ORDER INFORMATION

Scope of delivery

1 role (5 m)

Order reference / needed accessories

Order connecting accessories separately: connecting cable 2 m incl. clip connector (2-pin) 8mm, 24V. Straight connectors (2-pin) 8mm. 90° corner connectors (2-pin) 8mm. Order driver (smart or integrated) separately.

ACCESSORIES NEEDED
