CU4000 Control Unit, 24V, MW (2-pin), asynchro
DOCUMENTS

Technical Drawings

Installation manual

IES

KEY FEATURES

CU4000 Control Unit, 24V, MW (2-pin), asynchro
Article No. 111.11.01.001
  • matter ready – compatible with all matter-enabled devices (Thread border router required!), including brands such as Google Home, Apple HomeKit and Amazon Alexa that support matter.
  • Bluetooth ready – no wiring needed.
  • Modular system: One universal smart-driver and 8 control units that define application functions.
  • Easy stockkeeping and maximum flexibility.
Contact Us

PRODUCT VARIANTS

PRODUCT INFORMATION – BASIC

Subcategory of controller

multi-white asynchronous, 2 pin

Intended application

for switching on/off and dimming (0-100%) of LED lights for setting the colour temperature smart control for driver

Voltage (input)

24 V DC

Voltage (output)

24 V DC

Power rating W

max. 150 W (depends on the output wattage of LED driver)

Colour system

multiwhite

Connected output ports

6x 2-pin

Installation

only plugged into driver

Standby power consumption W

0,25 W

Current carrying capacity (output)

6,25 A max. (actual current depends on driver connected)

Additional information attributes

Each colour setting requires a specific model of control unit and a specific smart sensor switch or remote control. For seamless Smart Home integration, a Matter-compatible Smart Home device is required that also acts as a Thread border router, thereby supporting Matter-over-Thread. The specified power rating is the maximum capacity. The actual power rating depends on the connected smart-driver. Intended application: on / off, dimming (0-100%), colour temperature selection Signal range: Switches to control unit: 6 m. Control unit in Thread mesh: 10-30 m.

Scope of delivery

1 control unit

Order reference / needed accessories

Order smart-driver separately. Order smart sensor switch or remote control separately.
